Independent lab for side-channel analysis, fault injection, firmware reverse engineering and secure silicon. We test secure elements, TPMs, automotive MCUs, IoT, crypto wallets and industrial controllers — down to transistors.

240+devices tested
37CVE / disclosures
12years on silicon
100%independent
⚡ Vcc glitch: SUCCESS @ 1.2V
◉ AES key extracted in 14k traces
Secure microchip macro - hardware security research hwsec.net
root@hwsec-lab:~# chipshouter --arm --pulse 480V
[+] target: STM32H7 / nRF52 / ESP32-S3
[+] fault @ 0x080041A2 — secure boot bypassed ✓
# 14,203 traces | SNR 8.4dB | CPA key rank 1
FAULT INJECTION ◆ SIDE-CHANNEL ◆ FIRMWARE REVERSING ◆SECURE ELEMENT AUDIT ◆ PCB FORENSICS ◆ ANTI-TAMPER ◆CRYPTO IMPLEMENTATION ◆ SUPPLY CHAIN ◆EMFI ◆ LASER ◆ POWER ANALYSIS ◆
[ 01 — WHO WE ARE ]

About HWSEC.NET

We are engineers, not slideware. Oscillosopes, lasers, FIBs and decapsulation baths — not just checklists.

Hardware security laboratory with oscilloscopes and chip testing
HWSEC LAB — BERLIN / WARSAW / REMOTE

From PCB to transistor.
We own the full stack.

🛡️

Our mission

HWSEC.NET was founded to close the gap between software security hype and silicon reality. A buffer overflow is patchable. A ROM mask bug, a leaky regulator or a clonable secure element costs millions. We find those flaws before attackers do — with invasive, semi-invasive and non-invasive techniques.

We work with chip vendors, automotive Tier-1s, crypto wallet makers, medical and industrial OEMs, plus red teams who need ground truth about hardware trust anchors.

🔬

Invasive & EMFI

Decapsulation, microprobing, laser fault injection, electromagnetic glitching, power analysis up to 20GS/s.

💾

Firmware & crypto

Bootloader reversing, JTAG/SWD/UART extraction, custom crypto review, DPA/CPA, template attacks.

0Devices torn down
0CVEs & disclosures
0% keys extracted*
0Test benches

* on unprotected AES implementations under lab conditions. Protected targets vary — that's why you test.

[ 02 — WHAT WE DO ]

Research Vectors

Six core practices. One goal: prove what happens when physics meets cryptography.

PCB analysis and chip decapsulation

01 / Side-Channel Attacks

Power, EM, acoustic and timing analysis. CPA, DPA, MIA, deep-learning SCA against AES, RSA, ECC, Kyber.

ChipWhisperer20GS/s scopeLanger probes
Microchip fault injection testing

02 / Fault Injection

Voltage, clock, EM and laser glitching to bypass secure boot, readout protection and PIN checks.

EMFILaserVCC glitch
Cybersecurity firmware reverse engineering

03 / Firmware Reversing

Extraction via debug ports, flash dumping, bootloader vulnerabilities, Ghidra + custom loaders for exotic cores.

GhidraJTAGSPI dump
Server and secure element testing

04 / Secure Element Audit

Common Criteria style testing of SE, TPM 2.0, eSIM, smartcards: logical + physical, anti-tear, anti-clone.

TPMJavaCardeSE
PCB forensics microscope

05 / PCB Forensics

Counterfeit detection, X-ray, delayering, netlist recovery, implant / trojan hunting, BOM integrity.

X-raySEMNetlist
Woman engineer designing secure hardware

06 / Secure Design

Threat modeling, schematic review, PUF integration, anti-tamper meshes, secure provisioning for factories.

Threat modelPUFProvisioning
[ 03 — INSIDE ]

The Lab

15 benches. Faraday cage. Failure is data — every glitch is logged.

Oscilloscope bench for power analysis

SCA BENCH — 20GS/s

Keysight + Riscure + custom amplifiers. 14k traces to full AES break on unprotected Cortex-M.

Engineer with EM fault injection probe

EMFI / LASER CELL

DTS + ALPhANOV laser. 5μm spot, RDP bypass on STM32, nRF, SAM L11.

Chemical decapsulation and microprobing station

DECAp + MICROPROBING

Fuming nitric, plasma etch, FIB edits, needle probing of ROM buses.

Firmware reversing workstation dark

REVERSING FARM

40TB firmware corpus, JTAGulator fleet, Ghidra headless + ML-assisted triage.

[ 04 — HOW WE WORK ]

Attack Method

01 — Recon & Teardown

X-ray, PCB mapping, BOM analysis, debug port discovery, threat model. 3–5 days. You get a full hardware BoM + attack surface map.

02 — Non-invasive

UART/SWD/JTAG, firmware dump, bootloader fuzzing, power/EM capture. No damage, maximum signal.

03 — Semi-invasive

Voltage/clock/EM glitching, RDP downgrade, option byte attacks, crypto SCA with 10k–1M traces.

04 — Invasive

Decap, laser, microprobing, ROM extraction. For high-assurance targets and counterfeit proof.

05 — Report & Fix

Reproducible PoCs, video, CVSS-HW scoring, schematic-level fixes, retest included. No 200-page PDF fluff.

[ 05 — INTEL / BLOG ]

Latest News

Disclosures, teardowns, tooling and lab notes. Click any card to open full analysis.

[ 06 — FAQ ]

Hard Questions

What is HWSEC.NET exactly?

An independent hardware security lab. We do physical security testing: side-channel, fault injection, firmware extraction, PCB forensics and secure design review. Think pentest, but for silicon and boards.

How long does a hardware audit take?

Quick teardown: 1 week. Full black-box with glitching + SCA: 4–8 weeks. High-assurance with invasive work: 8–12 weeks. You get weekly demos, not silence.

Do you need source code / schematics?

No. We love black-box. If you have docs, we go faster and deeper — white-box lets us audit crypto implementations line-by-line and review schematics for anti-tamper gaps.

Will you destroy our devices?

Some will die heroically. Decap and laser are destructive by nature. We ask for 5–15 samples depending on target. Non-invasive phases are fully non-destructive.

Do you handle responsible disclosure?

Yes. 90-day coordinated disclosure by default, CVE assistance, vendor liaison, and retest after fix. We never sell zero-days.

READY WHEN YOU ARE

Send us your hardest board

NDA in 24h. Teardown quote in 72h. Ship 5 samples — we handle the rest, from Faraday cage to final PoC video.

Secure hardware testing - contact hwsec lab
Start with About →Read disclosures
PGP AVAILABLE ON REQUEST // [email protected] // RESPONSE < 24H
